Robert Koda Takumi K-160 Power Amplifier

The K-160 monaural power amplifiers represent the culmination of a decade of research that followed Koch's celebrated K-70 valve amplifier.

*Priced as a pair.

OVERVIEW

The K-160 monaural power amplifiers represent the culmination of a decade of research that followed Koch's celebrated K-70 valve amplifier.

FEATURES

Entirely solid-state, operating in pure Class A at 100% into any impedance, the K-160 employs only N-type transistors, eliminating crossover distortion entirely, and runs zero negative feedback throughout. Its reactor-based power supply provides a static, constant DC current feed to the output stage regardless of program demands, eliminating the modulated supply noise that compromises conventional designs. Output: 150 watts into 8 ohms, 230 watts into 4 ohms. Distortion: 0.0009% at 5 watts. Signal-to-noise: 125.5dB at 100 watts. Each K-160 weighs 45 kilograms and is assembled, tested, and personally approved by Koch.

SPECIFICATIONS



• Type
  • Solid-state, mono power amplifier
• Power output
  • 150W/8Ω, 230W/4Ω, 120W/2Ω
• Inputs
  • XLR (balanced), RCA (single-ended)
• Gain
  • 26dB (single-ended, balanced or floating)
• Input impedance
  • >10kΩ (single-ended, balanced or floating)
• Output impedance
  • 0.05Ω at 1kHz
• Damping factor
  • 160
• Signal to noise ratio
  • 105.5dB (A weighted) at 1W into 8Ω
  • 125.5dB at 100W into 8Ω
• Distortion (at 1kHz)
  • 0.0009% at 5W into 8Ω
  • 0.005% at 50W into 8Ω
• Weight
  • 45kg per unit

AVAILABILITY

This item is made to order. Typical production time is 6-8 months.

For in-store listening sessions please contact us to schedule a private listening session. An appointment is required for this bespoke item. CONTACT US HERE or SCHEDULE A DEMO
